1 Compact structure design, multi internal plastic buffer, sustain 1. 2 meters drop, Water proof, IP65 Industrial Standard
2 Super Power Battery 7.4V,2500MAH/3.7V,5000MAH, Long Working Time. Sustain consecutive Working above 20 hours (depends on specific situation), 10 days standby. Extended battery life.
3 Efficiency and power saving 1.2GHZ CPU System ,Long working time
4 Readable under sun-shine 3.5 inch LCD
5 Android 4.4 system
6 Hardware extendable functions
7 High capability Barcode scanner(optional) engine, Designed for 10 years using.
8 Sensitive RFID （LF/HF/UHF） Module
9 Wifi &BT( Standard), GPRS/3G(optional),GPS/Optional, Camera/Optional
10 Support further software development, SDK(Software Development Kit ) Provided
|
CPU |
|
1.2GHZ Due Core |
|
|
OS |
|
Android 4.4 |
|
|
Memory |
RAM |
1GB |
|
|
F-ROM |
4GB |
||
|
Barcode Scan engine |
Scanner |
1D /2D Laser Barcode Scanner |
|
|
Module |
Opticon /Moto |
||
|
Scan Speed |
100 times per second +-2 times |
||
|
Scan Distance |
60-650mm |
||
|
Angle |
54±5 |
||
|
Width |
60-360mm At Max Reading Distance |
||
|
Resolution |
0.127-1.00mm |
||
|
Code |
UPC-A; UPC-E; UPC-E1; EAN-8; EAN-13; Bookland EAN; Code 128; UCC/EAN-128; Code 39; Trioptic Code 39; Code 39 Full ASCII; Code 93; Code 11; Interleaved 2 of 5; Discrete 2 of 5; Codabar; MSI; GS1 DataBar 14; GS1 DataBar Limited; GS1 DataBar Expanded; |
||
|
RFID |
LF 125KHZ |
Max Reading 10cm |
|
|
LF 134.2KHZ |
Max Reading 10cm |
||
|
HF 13.56MHZ |
Max Reading 10cm |
||
|
UHF 860-928M |
Max Reading above 400cm |
||
|
LCD |
Type |
TFT-LED QVGA Touch Screen |
|
|
Resolution |
QVGA（240X320）Readable Under Sun Shine |
||
|
Size |
3.5 inch |
||
|
Input |
Soft Keyboard |
English, Chinese Input(Multi Language Customizable) |
|
|
Hard Keyboard |
30 Key |
||
|
ScanKey |
At the Middle |
||
|
Function Modules |
Standard |
|
|
|
Standard |
BT 3.0 |
||
|
Optional |
Internal 3M camera |
||
|
Optional |
Internal GPS Signal 48,Accuration 2.5m，Speed below 0.01m/s |
||
|
Optional |
Internal LF/HF/UHF RFID Reader |
||
|
Optional |
Internal GPRS/3G WCDMA |
||
|
Power |
Main Power |
7.4V,2500mah/3.7V 5000mah Li-ion |
|
|
RTC Battery |
Chargeable Button battery |
||
|
Standby |
10 days |
||
|
Working |
Above 20 hours, depends on specific situation |
||
|
Extension |
|
Micro SD/TF Slot |
|
|
Industrial Standard |
|
IP65 |
|
|
Size |
Human Engineering Design |
190(L)×78(W)×40(T) mm |
|
|
Weight |
|
430g( Including Battery) |
|
|
Working Environment |
Operation Temp. |
-15~+50℃ |
|
|
Storable Temp. |
-20~+60℃ |
||
|
Working Wet |
5-95% |
||
|
Storage Wet |
5-95% |
||
|
Anti-Drop |
50 inch(1.2Meters)Multi Drop |
