Hyintech UHF Animal Management is designed for big animals, like cow, pig, sheep and etc.
With the long reading distance feature, UHF changed the traditional animal management greatly.
l Standard Resolution
1) Using HYB804 uhf reader&writer with 4 pieces 8 dbi antenna installed at the entrance and exit of gate for animals. When the animals with ear tag HYTSA8070 passing through the gate, the tag information will be read. These 4 antennas gathering around the gate read tags from all angles, to prevent missing of tag reading.
2) Using rugged UHF handheld computer HY3800WU to check and input data of the tags.
This handheld can read HYTSA8070 at around 1 meter, easy operation, more safe for operating person
HY3800WU can transfer data through wifi or GPRS to host. It also with high quality barcode scanner, which could read the barcode from the tags in old system, if exist.
l Low cost Resolution
1) Using HYB608 integrated UHF reader&writer.
B608 is with one integrated antenna can only read the tags from one angle.(reading range of UHF reader please check the article “reading angle” in “Technology Exploit” sector on Hyintech home page)
UHF wave can be blocked by animal body.
If using HYB608 have to make sure the entrance and exit gate for animal is small enough for one animal to pass, and the reader have to be at the same side of ear tag.
(Standard Resolution above have no such problem)
2) Using rugged UHF handheld computer HY3800WU to check and input data of the tags.
This handheld can read HYTSA8070 at around 1 meter, easy operation, more safe for operating person
HY3800WU can transfer data through wifi or GPRS to host. It also with high quality barcode scanner, which could read the barcode from the tags in old system, if exist.
Hyintech HYTSA8070 is with special design and adaptation to reach the long distance and good operation effort. In current market, lots of other supplier are using the ordinary inlay stick into the plastic tag shelf, with reading distance can only be within 4 meters, even using 12 Dbi antenna. ( using 12 dbi antenna, HYTSA8070 can read for 10 meters) The PET material made the tag have certain effect on UHF wave, Hyintech have special resolution to correct it in tag antenna design.
More Detail of please check the Memo at this same webpage.
(80mm*70mm) UHF Animal Ear Tag
For Animal Management,With Hyintech Specialized Designed Tag antenna.
UHF RFID Separated Reader&Writer support 4 Antenna
Industrial Handheld Computer With Handle ,Long reading distance(20Meters) ,Super Power Battery ,WinCE 6.0 R3 , Language Customizable
UHF RFID Integrated Reader&Writer with 8DBI Antenna (Optional GPRS/WIFI/BT)
UHF RFID 8 DBI Antenaa for HYB804 Reader&Writer
Industrial Handheld Computer ,IP65 ,4 inch(1.2 Meters) Anti-Drop ,Super Power Battery ,WinCE 6.0 R3, Language Customizable
Here is the question from our clients
Using HY804 be with 12 dbi antenna is with reading range much more longer than using the 8 dbi one. Why you recommend us 8 dbi, not 12 dbi
Answers
Beside the reading distance, 8 Dbi and 12Dbi antenna have another difference.
8 Dbi antenna is with round polarization , but 12 Dbi is vertical polarization (all RFID antenna above 8 dbi have to be vertical polarization)
For vertical polarization antenna, reading distance will be greatly different, when the tag put at angle with the same polarization with reader. It means, some of the animal tag may be read from far away distance accidentally.
As round polarization have no such problem.
Besides, our HYTSA8070 is be with special design, with much more longer distance than similar products at current market, using 8 DBI is with reading distance long enough for animal management.
Hyintech HYTSA8070 is with special design and adaptation to reach the long distance and good operation effort. In current market, lots of other supplier are using the ordinary inlay stick into the plastic tag shelf, with reading distance can only be within 1.5 meters using 8Dbi antenna, 3 meters using 12 Dbi antenna. As our ear tag TSA8070 using 8 dbi antenna, can be read at 6 meters , and 12 DBI antenna can read it at 10 meters The PET material made the tag have certain effect on UHF wave, Hyintech have special resolution to correct it in tag antenna design.
